UniLight 16mm Pro Strobe Light, 8Wx2, T-Fuse - Green PRO16F-080x2-GN
Ultra Power 16mm strobe light with an extremely strong (8Wx2) light output and an excellent beam angle thanks to a special diffusion cap. The light is delivered as a fully assembled unit on an aluminum mounting plate, featuring an integrated thermal fuse and a removable polycarbonate cover.
The unit is pre-configured for operation on a 2S LiPo (~8V). When operating on 3S (12V), the additional resistor must be used; alternatively, you can also use an 8W-3S adapter cable.
Technical Data:
Electricity: 8W reference power,
Voltage: 8(12)V, 0.7A
Overheating protection: the lights will safely turn off/be cycled at 65-70°C.
Beam angle: >160°
Light intensity: ~200 Lumen RED
Light intensity: ~300 Lumen GREEN
Light intensity: ~400 Lumen WHITE
Dimension base panel: 16x37mm Overall
dimension: 17x38x9mm
Weight: 5g (without cable)
| Operating Voltage: 2S/8V or 3S/12V with additional resistor |
| Cable Length: 1m Silicone 0.25mm² |
| Design: profile-shaped |
| Function: Strobe |
| Dimensions: 16mm |
Delivery Content:
Equipped with 1m silicone cable and pre-configured resistor for 2S.
Warning Notice:
Please note that high-power LEDs can become very warm, up to 70°C is quite normal. These luminaires with heat sink mounting are suitable for continuous operation if air convection is possible. Check the operating temperatures after installation. We cannot accept any warranty due to overheating.
Warning: The LED lights are extremely bright! Never look directly into an LED!
