Overlander 5055/06 580KV Tornado Thumper V3 Brushless Outrunner RC Motor (IC .60 Equivalent) 2987
The 5055/06 580KV motor is part of Overlander's Tornado Thumper V3 range. These motors are manufactured to Overlander’s demanding standards, using the finest quality components and state of the art CNC machine tools. A total performance package when used in conjunction with our XP2 ESCs!
Specifications:
SKU: 2987
Barcode: 5060386112822
KV (rpm/V): 580
Power: 1280W
Idle Current: 2.3A
Maximum Amp Draw: 83A
Motor Type: Outrunner
Recommended ESC: 80A
LiPo Voltage Range: 3 - 8S
NiMH Voltage Range: 10 - 22S
Approx. Best Voltage: 6S
Minimum Propeller Size: 14 x 6 (with 8S LiPo)
Approx. Best Propeller Size: 15 x 8
Maximum Propeller Size: 17 x 10 (with 3S LiPo)
Shaft Diameter (mm): 6
Motor Poles: 14
Connector: 4mm Gold
Diameter (mm): 50
Length:55
KV (rpm/V): 580
Weight (g): 279
