Hitec D946TW Standard Digital Coreless Servo 68g 23kg/0.1s 4.8V - 7.4V 2221012

Save 10%
HitecSKU: 2221012

Price:
Sale price£135.89 Regular price£150.99
Stock:
In stock at supplier warehouse.  Lead time: 2-3 days
 More payment options

Description

Hitec D946TW Standard Digital Coreless Servo 68g 23kg/0.1s 4.8V - 7.4V 2221012

Sporting a full metal jacket Hitec's top end D946TW is a multi purpose, wide voltage, titanium gear servo that not only boasts impressive torque, but speed too.

Hitec's tradition of striving to continually advance servo technology has led to the new, hugely desirable, 32-bit D-Series, comprising the D941TW, D946TW and D951TW. Faster and more precise than ever before the programmable D946TW Multi Purpose servo is compatible with voltages of 4.8 to 7.4 and offers an impressive mid-range torque and speed of 23.0kg.cm and 0.10 sec/60deg at 7.4 volts. That's not the half of it though, check out the full specification then quietly admire the beautifully anodised full metal case and gorgeous build quality. This, then, is a jewel-like, weightlifting, go-faster, water resistant, masterpiece of a servo with the precision and visual appeal of a Swiss timepiece. It's hard not to want one.

Programming Functions

  • End Point Adjustments
  • Direction
  • Fail Safe
  • Dead Band
  • Speed (Slower)
  • Soft Start Rate
  • Overload Protection
  • Data Save / Load
  • Series - D-Series
  • Size - Standard
  • Dimensions - 40×20×38mm
  • Command Protocol - PWM
  • Circuit - Digital
  • Weight - 80 g
  • Voltage Range - 4.8V - 7.4V
  • Max Torque (kg/cm) - 23
  • Max Speed (sec/60°) - 0.1
  • Spline - 25T (Ø6mm)
  • Motor - Coreless
  • Gears - Titanium
  • Programmable - Yes
  • Dust/Water Resistance - Splashproof
  • Case - Aluminium Alloy
  • Bearings - Dual Ball Bearing
  • Circuit Detail - 32bit Programmable Digital
  • Motor Detail - Coreless Metal Brush
  • Compatible Horns - HT Horn [HD-IM, HD-LS, HD-OS, HD-XS, HD-IL, HD-LL, HD-IG, HD-LG] & HT Micro Horn [M-O, M-I, M-X] & HT Metal Horn [R-ML]
