Description
SPECIFICATIONS:
| KV: | 465 |
|---|---|
| Weight: | 384g |
| Dimensions (D x L): | 69 x 63mm |
| Length(Overall): | 95mm |
| Diameter of Shaft: | D8.0 x 32mm (Output) |
| Spec of Mounting Holes: | 55mm to 58mm |
| Slots,Poles: | 24, 28 |
| Idle Current(Io) @10V: | 2.5A |
| Resistance(Ri): | 12.0mOhm |
| No. Of Cells (Lipo): | 18.5 - 22.2V, 5 - 6S Lipo |
| Peak Power[15s]: | 2664W |
| Bursts current[15s] & MAX Torque: | 120A, 3.08N*M |
| Cruising Power[8 mins]: | 1330W |
| Propeller: | 17 x 8E to 18 x 8E for efficiency flight, Carbon Fibre 18 x 10E for pilots performance |
| Weight of Sports Airplane: | upto 9kg |
| Weight of 3D Airplane: | upto 4.1kg |
| Applications: | For 25cc class (equivalent to .120E) 3D airplane (upto 67in ~ 69in wingspan) |
