Futaba S9177SV Standard Servo HV S-BUS2 41.0Kg /0.11s 4.8V - 7.4V

Save 15%
FutabaSKU: FUT05102626-3
Price:
£110.25 £129.99
Stock:
Only 3 units left
 More payment options

Description

Futaba S9177SV Standard Servo HV S-BUS2 41.0Kg  0.11s 4.8V - 7.4V FUT05102626-3

The S9177SV is currently the most powerful standard size servo in the range, With an incredible 41 kg.cm of torque at 7.4V the S9177SV offers, arguably, the perfect balance between, size, torque, cost and quality. Dual ball raced with metal gears and an anodised metal case centre, the S9177SV is programmable, supports S.Bus2 and features soft start technology

Specifications
Case: Metal/Plastic
Gear Type: Metal Gear
Weight: 74g
Dimensions: 40.5 x 21 x 37.2m

Speed at 6.6V (sec): 0.12
Speed at 7.4V (sec): 0.11
Torque at 6.6V (kg.cm): 38.6
Torque at 7.4V (kg.cm): 41.0
Spline (teeth): 25
Input Voltage (V): 4.8 to 8.4
  • Size - Standard
  • Dimensions - 40.5×21.0×37.5mm
  • Circuit - Digital
  • Weight - 74 g
  • Voltage Range - 4.8 – 7.4
  • Spline - 25T
  • Motor - Coreless
  • Gears - Metal
  • Programmable - Yes
  • Case - Metal / Engineering Plastic
  • Bearings - Dual Ball Bearing
